Soldering tips and tricks

We find it easiest to start soldering the small components on the back side (where the Domingo logo is) so you can keep the PCB flat on your work surface.

The diode has a direction and therefore a line painted on its packaging. It indicates the ground. It goes to the side of the longest line seen on the PCB.

The Grove connectors have legs on both sides that must be soldered as well to strengthen the components in place. Especially because they will receive forces when connecting and disconnecting cables.

The direction of the Raspberry Pico can be seen from the small rectangle on the PCB indicating the Pico’s USB port. Solder it accordingly.
